A Review of Shaped Charge Variables for its Optimum Performance

Authors

  • K. Naeem School of Chemical and Materials Engineering, National University of Sciences and Technology, Islamabad, Pakistan
  • A. Hussain School of Chemical and Materials Engineering, National University of Sciences and Technology, Islamabad, Pakistan
  • S. Abbas Al Technique Corporation of Pakistan, Pakistan
Volume: 9 | Issue: 6 | Pages: 4917-4924 | December 2019 | https://doi.org/10.48084/etasr.3153

Abstract

Shaped charge is a device for focusing the chemical energy of explosives to a particular point or line for penetration or cutting purpose respectively. They are used for the penetration or cutting of various types of targets on land, water, underground, underwater, or air. Their shape is either conical or linear and consists of explosive, casing and liner. The liner is bent towards the central axis producing a thin hypervelocity jet by the energy released as a result of the explosive detonation. This jet is utilized against the target. Shaped charges can perforate or penetrate targets like aircrafts, ships, submarines, armored vehicles, battle tanks, and bunkers. This paper presents a detailed review of analytical works, computer simulations, and experimental results related to the liner. Among modern diagnostic techniques flash x-rays, radiography is most used in the experiments performed in the last 40 years. Powder metallurgy, which started in the late twentieth century raised the efficiency of shaped charges to new altitudes. The efficiency of the shaped charge depends on numerous factors such as explosive’s type, liner’s material, geometry and metallurgy, manufacturing technique, and casing thickness. Factors concerning the liner’s material, metallurgical advancements, and geometry are discussed chronologically and in detail.

Keywords:

conical liners, hemispherical liners, sintered powder liners, rolled homogenous armor
